2.0 PITCH系列
Commonly known as(俗稱):PH2.0排針
Material(材質):See list(詳見列表):
Colar(顏色):See list(詳見列表):
Mating with terminal(配合端子):TA2005B-T系列
Mating terminal(對手件):TA2005W系列
The product conform to the RoHS
(此產品符合RoHS要求)
Commonly known as(俗稱):PHD2.0端子
Material(材質):Phosphor Bronze(磷銅);
Applicabie wire(適用線徑):UL1007 AWG#24~#28;
Insulation 0.D(線皮外徑):?1.3~1.1mm:
Mates with housing(配合塑膠):TAH2006-2XNP Series;
Standard packing(包裝數量):10KPCS/Disc;
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):SAN2.0端子
Material(材質):PA66(UL94V-2);
Color(顏色):See List(見列表):
Mates with Terminal(配合端子):TBT2011 Series;
Standard packing(包裝數量):1KPCS/Bag:
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):PHD2.0膠殼
Material(材質):PA66(UL94V-0);
Color(顏色):See List(見列表):
DMates with Terminal(配合端子):TAT2006 Series;
Standard packing(包裝數量):1KPCS/Bag;
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):YH2.0端子
Material(材質):Phosphor bronze(磷青銅);
Applicabie wire(適用線徑):UL1007 AWG#24~30;
Insulation 0.D(線皮外徑):01.45~1.1mm;
Mates with housing(配合塑膠):TAH2008-NP Series;
Standard packing(包裝數量):15KPCS/Disc;
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):YH2.0膠殼
Material(材質):PA66 UL94 V-2;
Colar(顏色):See List(見列表):
Mates with Terminal(配合端子):TAT2008 Series;
Standard packing(包裝數量):1KPCS/Bag;
The product conform to the RoHS(此產品符合RoHS要求)
Commonly known as(俗稱):PHB2.0端子
Material(材質):Phosphor bronze(磷青銅);
Applicabie wire(適用線徑):UL1007 AWG#24~#28;
Insulation 0.D(線皮外徑):01.45~1.2mm;
Mates with housing(配合塑膠):TAH2012-NP Series;
Standard packing(包裝數量):10KPCS/Disc:
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):PHB2.0膠殼
Material(材質):PA66(UL94V-2):
Color(顏色):White(白色);
Mates with Terminal(配合端子):TAT2012 Series;
Standard packing(包裝數量):1KPCS/Bag;
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):DF3端子
MATERIAL(材質):Phosphor Bronze(磷銅);
Applicable wire(適用線徑):UL1007 AWG#22~#26;
Insulation O.D（線皮外徑）: 1.60~1.30mm;
Standard packing(包裝):10Kpcs/盤;
The product conform to the RoHS;
Commonly known as(俗稱):SAN2.0基端
Material(材質):Phosphor bronze(磷銅);
Applicabie wire(適用線徑):AWG#22~#28;
Insulation 0.D(線皮外徑):?1.60~1.20;
Mates with housing(配合塑膠):TBH2011-NP Series;
Standard packing(包裝數量):10KPCS/Disc;
The product conform to the RoHS(此產品符合RoHS要求)。
