插基板連接器
Commonly known as(俗稱):φ1.6基板端
Material(材質):Phosphor bronze(磷青銅);
Applicabie wire(適用線徑):UL1007 AWG#20~#24;
Insulation 0.D(線皮外徑):?1.85~1.45mm;
Mates with P.C.B.aperture(配合P.C.B.孔徑):1.6~1.7mm;
Mates with P.C.B.Tthinkness(配合P.C.B.厚度):1.6mm;
Standard packing(包裝數量):10KPCS/Disc;
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):φ1.8包線基板端
Material(材質):See list(詳見列表);
Applicabie wire(適用線徑):UL1007 AWG#18~#22;
Insulation 0.D(線皮外徑):?2.1~1.6mm;
Mates with P.C.B.aperture(配合P.C.B.孔徑):?1.8~2.0mm;
Mates with P.C.B.Tthinkness(配合P.C.B.厚度):01.6mm;
Standard packing(包裝數量):6.5KPCS/Disc;
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):φ1.4基板端
MATERIAL(材質):Phosphor Bronze(磷銅)；
Contact Plating(電鍍):See List(見列表)；
Applicable wire(適用線徑):UL1007 AWG#20~#22;
Insulation O.D（線皮外徑）：?1.85~1.60;
Standard packing(包裝):10KPCS/DISC;
The product conform to the RoHS;
(此產品符合ROHS指令要求);
Commonly known as(俗稱)：φ1.8基板端
MATERIAL(材質):Phosphor Bronze(磷銅)；
Contact Plating(電鍍):See List(見列表)；
Applicable wire(適用線徑):UL1007 AWG#18~#22;
Insulation O.D（線皮外徑）：?2.1~1.7;
Standard packing(包裝):8KPCS/DISC;
The product conform to the RoHS;(此產品符合ROHS指令要求);
Commonly known as(俗稱):SAN2.0端子
Material(材質):PA66(UL94V-2);
Color(顏色):See List(見列表):
Mates with Terminal(配合端子):TBT2011 Series;
Standard packing(包裝數量):1KPCS/Bag:
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):φ2.2包圓基板端
MATERIAL(材質):磷青銅;
Applicable wire(適用線徑):AWG#18-#22
Insulation 0.D(線皮外徑):02.1Max
Standard packing(包裝):6KPcs/R;
The product conform to the RoHS
(此產品符合RoHS指令要求)
Commonly known as(俗稱):φ2.2包圓基板端
Material(材質):Phosphor bronze(磷青銅):
Applicabie wire(適用線徑):UL1007 AWG#18~#22;
Insulation 0.D(線皮外徑):?2.1~1.60mm:
Mates with P.C.B.aperture(配合P.C.B.孔徑):2.2mm;
Mates with P.C.B.Tthinkness(配合P.C.B.厚度):1.6mm;
Standard packing(包裝數量):6KPCS/Disc;
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):φ2.5基板端
Material(材質):See list(詳見列表);
Applicabie wire(適用線徑):UL1007 AWG#18X2;
Insulation 0.D(線皮外徑):?2.1mm;
Mates with P.C.B.aperture(配合P.C.B.孔徑):2.3mm;
Mates with P.C.B.Tthinkness(配合P.C.B.厚度):1.8mm;
Standard packing(包裝數量):3KPCS/Disc;
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):SCN2.5端子
Material(材質):See list(詳見列表);
Applicabie wire(適用線徑):UL1007 AWG#20~#26;
Insulation 0.D(線皮外徑):01.85~1.3mm;
Mates with housing(配合塑膠):TBH2512-NP Series;
Standard packing(包裝數量):10KPCS/Disc;
The product conform to the RoHS(此產品符合RoHS要求);
Commonly known as(俗稱):SCN2.5膠殼
Material(材質):PA66 UL94 V-0;
Color(顏色):See List(見列表);
Mates with Terminal(配合端子):TBT2512PAS-T2# Series;
Standard packing(包裝數量):1KPCS/Bag:
The product conform to the RoHS(此產品符合RoHS要求)。
