Commonly known as(俗稱):φ1.6基板端
Material(材質):Phosphor bronze(磷青銅);
Applicabie wire(適用線徑):UL1007 AWG#20~#24;
Insulation 0.D(線皮外徑):?1.85~1.45mm;
Mates with P.C.B.aperture(配合P.C.B.孔徑):1.6~1.7mm;
Mates with P.C.B.Tthinkness(配合P.C.B.厚度):1.6mm;
Standard packing(包裝數量):10KPCS/Disc;
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):φ1.8包線基板端
Material(材質):See list(詳見列表);
Applicabie wire(適用線徑):UL1007 AWG#18~#22;
Insulation 0.D(線皮外徑):?2.1~1.6mm;
Mates with P.C.B.aperture(配合P.C.B.孔徑):?1.8~2.0mm;
Mates with P.C.B.Tthinkness(配合P.C.B.厚度):01.6mm;
Standard packing(包裝數量):6.5KPCS/Disc;
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):大六P端子
MATERIAL(材質):Brass(黃銅);
Mates with housing(配合塑膠):TA250H-6P;
Applicable wire(適用線徑):AWG#14~#20;
Standard packing(包裝):5KPcs/R;
The product conform to the RoHS;
Commonly known as(俗稱):250膠殼
MATERIAL(材質）:See List(見列表);
Colar(顏色):Black(黑色);
Mates with terminal(配合端子):See List(見列表);
The product conform to the RoHS; (此產品符合RoHS)
Commonly known as(俗稱):MOLEX1.0端子
Material(材質):See list(詳見列表);
Applicabie wire(適用線徑):UL1007 AWG#30~#34:
Insulation 0.D(線皮外徑):01.05mm MAX:
Mates with housing(配合塑膠):TAH1002-NP Series:
Standard packing(包裝數量):20KPCS/Disc;
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):MOLEX1.0膠殼
Material(材質):PA66 GF15(UL94V-0);
Color(顏色):See List(見列表):
Mates with Terminal(配合端子):TAT1002 Series;
Standard packing(包裝數量):1KPCS/Bag:
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):110公端
MATERIAL(材質):Brass(黃銅);
Mates with housing(配合塑膠):TA1101H系列
Applicable wire(適用線徑):See List(見列表);
Insulation 0.D(線皮外徑):See List(見列表);
Standard packing(包裝):4.5KPcs/Disc;
The product conform to the RoHS;
(此產品符合ROHS指令要求);
Commonly known as(俗稱):110母殼
Material(材質):PA66(UL94V-2);
Color(顏色):Natural(本色):
Mates with Terminal(配合端子):TAT1101 Series:
Standard packing(包裝數量):1KPCS/Bag:
The product conform to the RoHS(此產品符合RoHS要求)。
Commonly known as(俗稱):PH2.0端子
MATERIAL(材質):Phosphor Bronze磷青銅;
Contact Plating(電鍍):80u＂Tin over 20u" Nickel;
Plating(鍍色):Tin-Plated;
Mates with housing(配合塑膠):TC2001H-NP系列;
Applicable wire(適用線徑)：AWG#24~#28;
Standard packing(包裝):10KPcs/Disc;
The product conform to the RoHS;
